Description
Technical Parameters:
| Series | Multi-Tube Vortex Mixer |
| Function | Mixing / Oscillation / Stirring |
| Speed | 500 – 2500 rpm |
| Amplitude | 4 mm |
| Motion Trajectory | Horizontal Rotation |
| Maximum Sample Volume | Optional Modules |
| Handling Mode | Multi-Tube |
| Timer Range | Yes |
| Motor Type | Brushless DC Motor |
| Power | 60 W |
| Vibration Mode | Continuous / Press-and-Mix |
| Dimensions (mm) | 426 × 250 × 480 |
| Model | Vortex X2 | Vortex X2 Pro |
| Display | Color LCD | Color LCD |
| Power Supply | AC 100–240V, 50/60 Hz | AC 100–240V, 50/60 Hz |
| Power | 30 W | 30 W |
| Handling Mode | Single / Multi-Tube | Single / Multi-Tube |
| Speed Range | 200–3000 rpm (Each module up to 3000 rpm) | 0–4000 rpm (Each module up to 4000 rpm) |
| Timer Range | 1–99 min | 1–99 min |
| Motor Type | Brushless DC Motor | Brushless DC Motor |
| Operation Mode | Linked / Press-and-Mix | Linked / Press-and-Mix |
| Amplitude | 4.5 mm (Circular Oscillation) | 4.5 mm (Circular Oscillation) |
| Maximum Sample Volume | 50 ml × 4 | 50 ml × 4 |
| Single Tube Volume | 0–50 ml | 0–50 ml |
| Compatible Tube Diameter | ≤ Φ30 mm | ≤ Φ30 mm |
| Product Dimensions (mm) | 130 × 150 × 115 | 130 × 150 × 115 |
| Net Weight | 3.2 kg | 3.2 kg |
