Features

PCR thermal cycler is the fundamental instrument that provide specific temperature cycling for PCR reactions and facilitate DNA amplification . Tianlong Gentier X3 Series real-time PCR equipment features three independent thermal blocks , supporting users to run a maximum 3×32 well samples in three different protocols simultaneously . This feature can help you save a lot of time and budget . With the powerful and efficient temperature control…

SKU: TIANLONG-GENTIER-X3-SERIES-REAL-TIME-PCR-SYSTEM Category: PCR Systems & Thermal Cyclers Tags: laboratory products, Molecular Diagnostics, PCR Systems & Thermal Cyclers, Tianlong Brand: Tianlong

Scientific China

Store

Scientific China

Store

People Also Viewed

Shipping

Additional information

Manufacturer	Tianlong
Model	Gentier X3E, Gentier X3S, Gentier X3R, Gentier X3C
Touch Screen Stand Alone Operation	YES, NO, YES, NO
Stand Alone Operation	YES, NO, YES, NO
Throughput	32 х 3, 32 х 3, 32 х 3, 32 х 3
Certificate	CE; CB; RoHS, CE; CB; RoHS, CE; CB; RoHS, CE; CB; RoHS
Fluorescence Scanning Time	2s for 32 wells fluorescence scanning, 2s for 32 wells fluorescence scanning, 2s for 32 wells fluorescence scanning, 2s for 32 wells fluorescence scanning
Fluorescence Channels	6, 6, 4, 4
Dye Compatibility	Channel 1: FAM, SYBR Green I, etc. Channel 2: HEX, TET, VIC, JOE, etc. Channel 3: Texas Red, ROX, etc. Channel 4: Cy5, etc. Channel 5: Alexa Fluor 680, etc. Channel 6: Tamra, Cy3, NED, etc., Channel 1: FAM, SYBR Green I, etc. Channel 2: HEX, TET, VIC, JOE, etc. Channel 3: Texas Red, ROX, etc. Channel 4: Cy5, etc. Channel 5: Alexa Fluor 680, etc. Channel 6: Tamra, Cy3, NED, etc., Channel 1: FAM, SYBR Green I, etc. Channel 2: HEX, TET, VIC, JOE, etc. Channel 3: Texas Red, ROX, etc. Channel 4: Cy5, etc., Channel 1: FAM, SYBR Green I, etc. Channel 2: HEX, TET, VIC, JOE, etc. Channel 3: Texas Red, ROX, etc. Channel 4: Cy5, etc.
Heating Rate	Average Heating Rate: ≥ 4.5°C/s ; Max. Heating Rate: ≥6.2°C/s, Average Heating Rate: ≥ 4.5°C/s ; Max. Heating Rate: ≥6.2°C/s, Average Heating Rate: ≥ 4.5°C/s ; Max. Heating Rate: ≥6.2°C/s, Average Heating Rate: ≥ 4.5°C/s ; Max. Heating Rate: ≥6.2°C/s
Cooling Rate	Average Cooling Rate: ≥ 3.5°C/s; Max. Cooling Rate: ≥ 5.0°C/s, Average Cooling Rate: ≥ 3.5°C/s; Max. Cooling Rate: ≥ 5.0°C/s, Average Cooling Rate: ≥ 3.5°C/s; Max. Cooling Rate: ≥ 5.0°C/s, Average Cooling Rate: ≥ 3.5°C/s; Max. Cooling Rate: ≥ 5.0°C/s
Temperature Accuracy	≤0.1℃, ≤0.1℃, ≤0.1℃, ≤0.1℃
Temperature Uniformity	±0.2℃, ±0.2℃, ±0.2℃, ±0.2℃
Temperature Precision	≤ 0.1°C, ≤ 0.1°C, ≤ 0.1°C, ≤ 0.1°C
Repeatability	CV ≤ 1%, CV ≤ 1%, CV ≤ 1%, CV ≤ 1%
Linear Correlation	│r│≥ 0.995, │r│≥ 0.995, │r│≥ 0.995, │r│≥ 0.995
Sample Cabin	Three independent sample cabin, Three independent sample cabin, Three independent sample cabin, Three independent sample cabin
Lightsource	High-brightness, long-life, maintenance-free LED light source, High-brightness, long-life, maintenance-free LED light source, High-brightness, long-life, maintenance-free LED light source, High-brightness, long-life, maintenance-free LED light source
Key Applications	Absolute quantification analysis, relative quantification analysis, melting curve, high resolution melting (HRM), genotyping, end point fluorescence, etc., Absolute quantification analysis, relative quantification analysis, melting curve, high resolution melting (HRM), genotyping, end point fluorescence, etc., Absolute quantification analysis, relative quantification analysis, melting curve, high resolution melting (HRM), genotyping, end point fluorescence, etc., Absolute quantification analysis, relative quantification analysis, melting curve, high resolution melting (HRM), genotyping, end point fluorescence, etc.
Special Temperature Protocol	Touchdown step, long step, gradient step, standard step and so on., Touchdown step, long step, gradient step, standard step and so on., Touchdown step, long step, gradient step, standard step and so on., Touchdown step, long step, gradient step, standard step and so on.
Data Storage	1000 results can be stored in machine, 1000 results can be stored in machine, 1000 results can be stored in machine, 1000 results can be stored in machine
Power Failure Protection	Automatically start running experiments after power supply, Automatically start running experiments after power supply, Automatically start running experiments after power supply, Automatically start running experiments after power supply
Communication Specification	Network Port: TCP/IP protocol; Ethernet connection; USB Port: 2.0;, Network Port: TCP/IP protocol; Ethernet connection; USB Port: 2.0;, Network Port: TCP/IP protocol; Ethernet connection; USB Port: 2.0;, Network Port: TCP/IP protocol; Ethernet connection; USB Port: 2.0;
Power Supply and Power Consumption	AC 100~240V;50/60Hz; 1000VA;, AC 100~240V;50/60Hz; 1000VA;, AC 100~240V;50/60Hz; 1000VA;, AC 100~240V;50/60Hz; 1000VA;
Suitable Consumables	Conventional 0.2 mL 8-strip PCR tube (clear, white) Tianlong specialized 0.2 mL 8-strip PCR tube (clear, white), Conventional 0.2 mL 8-strip PCR tube (clear, white) Tianlong specialized 0.2 mL 8-strip PCR tube (clear, white), Conventional 0.2 mL 8-strip PCR tube (clear, white) Tianlong specialized 0.2 mL 8-strip PCR tube (clear, white), Conventional 0.2 mL 8-strip PCR tube (clear, white) Tianlong specialized 0.2 mL 8-strip PCR tube (clear, white)

Questions & Answers

Product Enquiry

Description

Gentier X3 Series Real-Time PCR System

Why choose the Gentier X3 Series Real-Time PCR System?

Gentier X3 Series is a 3 block PCR machine. It can process a maximum 3×32-well samples in three different protocols at the same time.
With 6 or 4 fluorescence channels depending on the model, GentierX3 Series can complete 32 wells of fluorescence scanning in one block within 2s, serving as a great boost to the PCR testing efficiency when there is a high throughput need.
The Gentier X3 Series PCR cycler delivers precise temperature control (≤ 0.1℃) along with a compensation heating function for accurate reactions and uses a hot lid with pressure sensing to prevent consumable deformation and evaporation.
Gentier X3 Series can offer multiple functions including absolute quantification analysis, relative quantification analysis, melting curve, high resolution melting (HRM), genotyping, endpoint fluorescence, etc.
The Gentier X3 Series PCR thermal cycler systems feature a 13.3-inch full-color touch screen adjustable for ergonomic viewing, offers standalone and PC control options, and includes power failure protection to automatically resume experiments.

Technical specifications

Model	Gentier X3E \| Gentier X3S \| Gentier X3R \| Gentier X3C
Touch Screen Stand Alone Operation	YES \| NO \| YES \| NO
Stand Alone Operation	YES \| NO \| YES \| NO
Throughput	32 х 3 \| 32 х 3 \| 32 х 3 \| 32 х 3
Certificate	CE; CB; RoHS \| CE; CB; RoHS \| CE; CB; RoHS \| CE; CB; RoHS
Fluorescence Scanning Time	2s for 32 wells fluorescence scanning \| 2s for 32 wells fluorescence scanning \| 2s for 32 wells fluorescence scanning \| 2s for 32 wells fluorescence scanning
Fluorescence Channels	6 \| 6 \| 4 \| 4
Dye Compatibility	Channel 1: FAM, SYBR Green I, etc. Channel 2: HEX, TET, VIC, JOE, etc. Channel 3: Texas Red, ROX, etc. Channel 4: Cy5, etc. Channel 5: Alexa Fluor 680, etc. Channel 6: Tamra, Cy3, NED, etc. \| Channel 1: FAM, SYBR Green I, etc. Channel 2: HEX, TET, VIC, JOE, etc. Channel 3: Texas Red, ROX, etc. Channel 4: Cy5, etc. Channel 5: Alexa Fluor 680, etc. Channel 6: Tamra, Cy3, NED, etc. \| Channel 1: FAM, SYBR Green I, etc. Channel 2: HEX, TET, VIC, JOE, etc. Channel 3: Texas Red, ROX, etc. Channel 4: Cy5, etc. \| Channel 1: FAM, SYBR Green I, etc. Channel 2: HEX, TET, VIC, JOE, etc. Channel 3: Texas Red, ROX, etc. Channel 4: Cy5, etc.
Heating Rate	Average Heating Rate: ≥ 4.5°C/s ; Max. Heating Rate: ≥6.2°C/s \| Average Heating Rate: ≥ 4.5°C/s ; Max. Heating Rate: ≥6.2°C/s \| Average Heating Rate: ≥ 4.5°C/s ; Max. Heating Rate: ≥6.2°C/s \| Average Heating Rate: ≥ 4.5°C/s ; Max. Heating Rate: ≥6.2°C/s
Cooling Rate	Average Cooling Rate: ≥ 3.5°C/s; Max. Cooling Rate: ≥ 5.0°C/s \| Average Cooling Rate: ≥ 3.5°C/s; Max. Cooling Rate: ≥ 5.0°C/s \| Average Cooling Rate: ≥ 3.5°C/s; Max. Cooling Rate: ≥ 5.0°C/s \| Average Cooling Rate: ≥ 3.5°C/s; Max. Cooling Rate: ≥ 5.0°C/s
Temperature Accuracy	≤0.1℃ \| ≤0.1℃ \| ≤0.1℃ \| ≤0.1℃
Temperature Uniformity	±0.2℃ \| ±0.2℃ \| ±0.2℃ \| ±0.2℃
Temperature Precision	≤ 0.1°C \| ≤ 0.1°C \| ≤ 0.1°C \| ≤ 0.1°C
Repeatability	CV ≤ 1% \| CV ≤ 1% \| CV ≤ 1% \| CV ≤ 1%
Linear Correlation	│r│≥ 0.995 \| │r│≥ 0.995 \| │r│≥ 0.995 \| │r│≥ 0.995
Sample Cabin	Three independent sample cabin \| Three independent sample cabin \| Three independent sample cabin \| Three independent sample cabin
Lightsource	High-brightness, long-life, maintenance-free LED light source \| High-brightness, long-life, maintenance-free LED light source \| High-brightness, long-life, maintenance-free LED light source \| High-brightness, long-life, maintenance-free LED light source
Key Applications	Absolute quantification analysis, relative quantification analysis, melting curve, high resolution melting (HRM), genotyping, end point fluorescence, etc. \| Absolute quantification analysis, relative quantification analysis, melting curve, high resolution melting (HRM), genotyping, end point fluorescence, etc. \| Absolute quantification analysis, relative quantification analysis, melting curve, high resolution melting (HRM), genotyping, end point fluorescence, etc. \| Absolute quantification analysis, relative quantification analysis, melting curve, high resolution melting (HRM), genotyping, end point fluorescence, etc.
Special Temperature Protocol	Touchdown step, long step, gradient step, standard step and so on. \| Touchdown step, long step, gradient step, standard step and so on. \| Touchdown step, long step, gradient step, standard step and so on. \| Touchdown step, long step, gradient step, standard step and so on.
Data Storage	1000 results can be stored in machine \| 1000 results can be stored in machine \| 1000 results can be stored in machine \| 1000 results can be stored in machine
Power Failure Protection	Automatically start running experiments after power supply \| Automatically start running experiments after power supply \| Automatically start running experiments after power supply \| Automatically start running experiments after power supply
Communication Specification	Network Port: TCP/IP protocol; Ethernet connection; USB Port: 2.0; \| Network Port: TCP/IP protocol; Ethernet connection; USB Port: 2.0; \| Network Port: TCP/IP protocol; Ethernet connection; USB Port: 2.0; \| Network Port: TCP/IP protocol; Ethernet connection; USB Port: 2.0;
Power Supply and Power Consumption	AC 100~240V;50/60Hz; 1000VA; \| AC 100~240V;50/60Hz; 1000VA; \| AC 100~240V;50/60Hz; 1000VA; \| AC 100~240V;50/60Hz; 1000VA;
Suitable Consumables	Conventional 0.2 mL 8-strip PCR tube (clear, white) Tianlong specialized 0.2 mL 8-strip PCR tube (clear, white) \| Conventional 0.2 mL 8-strip PCR tube (clear, white) Tianlong specialized 0.2 mL 8-strip PCR tube (clear, white) \| Conventional 0.2 mL 8-strip PCR tube (clear, white) Tianlong specialized 0.2 mL 8-strip PCR tube (clear, white) \| Conventional 0.2 mL 8-strip PCR tube (clear, white) Tianlong specialized 0.2 mL 8-strip PCR tube (clear, white)
Dimension	380mm(L) × 410mm (W) × 395mm (H) \| 380mm(L) × 410mm (W) × 395mm (H) \| 380mm(L) × 410mm (W) × 395mm (H) \| 380mm(L) × 410mm (W) × 395mm (H)
Weight	34kg \| 34kg \| 34kg \| 34kg
Touch Screen	YES \| NO \| YES \| NO
Temperature Precision	│r│≥ 0.995 \| │r│≥ 0.995 \| │r│≥ 0.995 \| │r│≥ 0.995
Key Applications	High-brightness, long-life, maintenance-free LED light source \| High-brightness, long-life, maintenance-free LED light source \| High-brightness, long-life, maintenance-free LED light source \| High-brightness, long-life, maintenance-free LED light source
1000 results can be stored in machine	Automatically start running experiments after power supply \| Automatically start running experiments after power supply \| Automatically start running experiments after power supply \| Automatically start running experiments after power supply

Applications

Suitable for professional laboratories, hospitals, diagnostic centers, research facilities, and other qualified users requiring pcr systems & thermal cyclers.
