Shinva Energy-saving/Heat Pump Double-Effect Concentrator

Shinva Energy-saving/Heat Pump Double-Effect Concentrator

The Shinva Energy-saving/Heat Pump Double-Effect Concentrator is pharmaceutical extraction and process equipment developed for pharmaceutical, botanical-extract, food, and chemical production facilities. It can be specified around the required process, production capacity, container or material format, automation level, utilities, and facility layout. Scientific China supports international buyers with equipment selection, export coordination, and project-based quotations.

Typical applications

• Herbal or botanical extraction and concentration
• Controlled process preparation and material handling
• GMP-oriented production projects and line integration

Key features and process capabilities

• Energy-saving double-effect concentrator: the secondary steam of the first-effect is used as the heat source of the second-effect to heat the materials, which improves the utilization rate of heat energy.
• Heat pump double-effect concentrator: the secondary steam of the first-effect is compressed by the heat pump and then supplied for the second-effect heating, thus greatly saving the consumption of boiler steam and reducing the production cost.
• Heat pump system (or vacuum), first-effect heating chamber, first-effect evaporation chamber, second-effect heating chamber,second-effect evaporation chamber, condenser, liquid receiving tank system pipes and valves.
• Double-effect operation index of heat pump:
• The live steam pressure is 0.5 ~ 0.7 MPa. The first-effect heating temperature is 90’c, and the first-effect evaporation temperature is 75 C); The second-effect heating temperature is 75’c, and the second-effect evaporation temperature is 55°C.
• Energy Saving Index:

Operational and procurement benefits

• Supports industrial batch-processing workflows
• Project configuration can be matched to process requirements
• Documentation, utilities, and installation scope can be quoted

Configuration and quotation

Final specifications, included modules, construction materials, control system, compliance documents, factory testing, installation, commissioning, training, warranty, and destination-market availability depend on the selected configuration. Contact Scientific China to confirm the appropriate model, minimum order quantity, price, lead time, and international delivery terms before purchase.
