ONH5000 Oxygen, Nitrogen & Hydrogen Analyzer

Features

The ONH5000 determines oxygen, nitrogen, and hydrogen in solid materials. The modular instrument is intended for metals, ceramics, semiconductor materials, and other suitable samples.

Estimated equipment price only. Shipping, import duties, installation, and logistics are additional and vary by destination and shipping method. We will contact you to confirm the total cost before processing your order.

Additional technical information

The ONH5000 Oxygen, Nitrogen, and Hydrogen Analyzer utilizes an inert gas-protected pulse furnace for melting and decomposition of samples. It measures oxygen via infrared absorption and nitrogen and hydrogen via thermal conductivity detection. The instrument is capable of simultaneously determining the content of oxygen, nitrogen, and hydrogen, or measuring each element individually as needed.

Equipped with an 8.0 kW pulse electrode furnace under inert gas protection, the ONH5000 achieves temperatures exceeding 3500°C. The furnace features program-controlled temperature ramping, with selectable power or current-controlled heating modes, ensuring complete and controlled sample decomposition. Depending on the target element, either helium or nitrogen is used as the carrier gas.

The carrier gas transports these gases to a conversion furnace, where CO is oxidized to CO₂. The mixed gases then pass through the infrared detection system, where CO₂ is quantified. The remaining gas mixture (containing N₂ and H₂, with CO₂ removed) is routed to the thermal conductivity detector for the measurement of nitrogen and hydrogen.
