FOUR E’s Scientific Recirculating Chiller
Available in stock
Discover the recirculating chiller from FOUR E's Scientific. Fast cooling from room temperature to -20°C in just 30 minutes. Perfect for rotary evaporators. Request configuration, MOQ and a formal quotation from Scientific China.
Scientific China
Store| Manufacturer | FOUR E's Scientific |
|---|---|
| Model | CH800 |
| Product type | Recirculating Chiller |
| Application | controlled heating, cooling and temperature-dependent sample preparation |
Product Enquiry
Description
FOUR E’s Scientific Recirculating Chiller
Product overview
The FOUR E’s Scientific Recirculating Chiller is a professional recirculating chiller designed for research, clinical and quality-control laboratories. It supports controlled heating, cooling and temperature-dependent sample preparation while helping laboratories improve consistency, efficiency and workflow organization.
Key features
- Recirculating Chiller CH800 provides an economic and environmentally friendly cooling solution for many laboratory applications.
- With precise temperature control, the device achieves excellent temperature stability and is suitable for a wide range of applications including cooling of rotary evaporators, reactor blocks, vapor barriers, or heat exchangers.
- The chiller, also known as recirculating chiller, is a cooling device that provides a continuous supply of water at a constant temperature and pressure.
- It cools water through the cooling system, delivers cool water to the equipment required via pump to remove heat and flows back to the bath..
Technical specifications
| Model | CH800 |
|---|---|
| Working temperature range | -20°C RT |
| Cooling capacity | @20°C — 750W |
| @10°C | 650W |
| @0°C | 500W |
| @-10°C | 400W |
| @-20°C | 200W |
| Time to cool from RT (25°C) down to -20℃ | ≤40min |
| Pump Flow Max. | 22 L/min |
| Pump pressure Max. | 1 bar |
| Bath volume | 5 L (max storage 5.3L) |
| Temperature stability DIN 12876 | ±0.3 K |
| Temperature Display Accuracy | ±0.3°C |
| Refrigerant | R290 |
| Power supply | 100-120VAC/200-240VAC; 50Hz/60H |
| Wattage | Max 750W |
| Weight | ≤35Kg |
| Dimension(WxDxH) | 235×468×535 mm |
| Noise | <55db |
Applications
Suitable for research, clinical and quality-control laboratories, subject to the selected configuration and applicable local requirements.
Ordering and quotation
Contact Scientific China for configuration selection, compatible accessories or consumables, minimum order quantity, lead time, warranty, documentation and international delivery.
