Drawell Horizontal Laminar Flow Cabinet HS-840U
Product overview
The outer shell is made of cold-rolled steel plate with electrostatic powder coating; the worktable is made of SUS304 brushed stainless steel, which is corrosion-resistant and easy to clean.
The Drawell Horizontal Laminar Flow Cabinet HS-840U supports clinical, research, pharmaceutical, industrial, and educational laboratories. Scientific China provides model selection, configuration review, export coordination, and formal quotations.
Key features
- Adopt an arbitrary positioning sliding door system.
- The outer shell is made of cold-rolled steel plate with electrostatic powder coating; the worktable is made of SUS304 brushed stainless steel, which is corrosion-resistant and easy to clean.
- Lighting and sterilization systems are interlocked for safety.
- Digital display control interface with three adjustable fan speeds (fast, medium, and slow) and UV lamp timer, offering a more user-friendly design.
- Vertical quasi-closed worktable; the formation of a downward airflow curtain in the operating room effectively prevents external gas from entering and maintains the cleanliness of the operating area.
- Equipped with a HEPA filter and a pre-filter for preliminary filtration, effectively extending the lifespan of the HEPA filter.
- Specifications of Horizontal Laminar Flow Cabinet HS-840U
Applications
- Protected handling, ventilation, containment, or laboratory workspace setup
- Facility-specific laboratory safety and workflow applications
- Research, testing, and sample-preparation environments
Technical specifications
| Model Spec. | HS-840U |
|---|---|
| Cleanliness | Class 100 @ ≥0.5μM (US Federal Standard 209E) |
| Colony count | ≤0.5 cells/plate·hour (Φ90mm culture plate) |
| Average wind speed | 0.25～0.45m/s (three speeds adjustable) |
| Noise | ≤62dB（A） |
| Illuminance | ≥300Lx |
| Power supply | AC single phase 220V/50Hz |
| Max. Power consumption | 490W |
| Work area size W*D*H mm | 700*570*700 |
| External dimensionW*D*H mm | 860*760*1750 |
| Application | One person use single operational side |
| HEPA filter | 675×690×50 ×①|
| LED/UV lamps | 8W×①/20W×①|
Ordering and configuration
Final specifications, included accessories, consumables, software, certifications, power requirements, installation, warranty, and regulatory availability depend on the selected model and destination. Contact Scientific China to confirm the suitable configuration, minimum order quantity, price, lead time, documentation, and international delivery terms before purchase.
