Drawell HBDV-2 Digital Viscometer
Available in stock
The Drawell HBDV-2 Digital Viscometer is a professional professional laboratory instrument. Review features and technical specifications, then request configuration, MOQ, lead time, warranty, and a formal quotation.
SKU: DRAWELL-9CDC590C6D
Category: Digital Viscometer
Tags: Digital Viscometer, Drawell, HBDV-2 Digital Viscometer, laboratory equipment
Brand: Drawell
Report Abuse
Scientific China
Store
Scientific China
StorePeople Also Viewed
-
RayKol Vitae 60 PCR Setup Automatic System — Estimated Price US$25,000–US$65,000
-
RayKol Vitae M96S Semi-Automatic Liquid Handling Workstation — Estimated Price US$18,000–US$45,000
-
RayKol EVA Mini 96 96-Well Plate Sample Drier — Estimated Price US$8,000–US$22,000
-
RayKol SAP 20 Automatic Dried Blood Spot Puncher — Estimated Price US$15,000–US$40,000
-
RayKol Mini Lids Automatic Capping Machine — Estimated Price US$6,000–US$18,000
-
Sineo ECH-II Temperature-Controlled Heating Block
Shipping
Additional information
| Product Category | Digital Viscometer |
|---|
Questions & Answers
Loading...
Product Enquiry
Product Enquiry
Description
Drawell HBDV-2 Digital Viscometer
Product overview
HBDV-2 Digital Viscometer Options of HBDV-2 Digital Viscometer The main technical indicators of HBDV-2 Digital Viscometer Apparatus to be equipped of HBDV-2 Digital Viscometer Other Digital Viscometer NDJ-8S 20-2000000mPa·s Low Viscosity Viscometer RVDV-2H High-Temperature Digital Viscometer LVDV-1 Digital Viscometer HBDV-1H High-Temperature Digital Viscometer HBDV-2H High-Temperature Digital Viscometer LVDV-2H High-Temperature Digital Viscometer RVDV-1 80-40000000mPa·s Medium Viscosity Viscometer LVDV-1 12-6000000mPa·s Low Viscosity Viscometer HBDV-1 60-320000000mPa·s High Viscosity Viscometer LVDV-2 6-6000000mPa·s Low Viscosity Viscometer
The Drawell HBDV-2 Digital Viscometer supports research, clinical, industrial, education, and quality-control laboratories. Scientific China provides model selection, configuration review, export coordination, and formal quotations.
Key features
- Extreme low viscometer adapter (with one spindle L0)
- Small sample adapter (with spindle 21, 27, 28 and 29 each)
- Temperature-controlled heater (with spindle 21, 27, 28 and 29 each)
- Special software that can complete the function in collecting the data automatically
- DV program control download software
- Specially used printer
Applications
- Professional laboratory testing or sample-processing workflows
- Routine research and quality-control applications
- Application-specific operation according to the selected model
Technical specifications
| Measuring Range（mPa·s） | 320～320,000,000 |
|---|---|
| Rotating Speed (RPM) | 0.1 ～ 200 （Stepless Gear） |
| Number of Spindles | Spindles (Code R2,R3,R4,R5,R6,R7) are equipped with the product |
| Accuracy | ±1% full scale range in use |
| Repeatability | ±0.5% full scale range in use |
| Readability | 1.when viscosity is lower than 10.0 cp : 0.01 2.when viscosity is lower than 10000 cp : 0.1 3.when viscosity is equal or higher than 10000 cp : 1 |
| Power | Power adapter ( input: 100-240V，50/60Hz) |
| LCD screen display | The LCD screen can display the viscosity, speed, torque spindle, temperature，shear rate, shear force and the maximum viscosity can be measured in the current spindle speed value. |
| digital viscosity meter | 1 pce | ascending and falling rack | 1 set |
|---|---|---|---|
| standard spindle | 1 set | power adapter | 1 pce |
| protective frame of spindle | 1 pce | spanner | 1 pce |
| Seat and leveling feet | 1 set | RS232 standard output interface | 1 pce |
| RTD temperature probe | 1 pce |
Ordering and configuration
Final specifications, included accessories, consumables, software, certifications, power requirements, installation, warranty, and regulatory availability depend on the selected model and destination. Contact Scientific China to confirm the suitable configuration, minimum order quantity, price, lead time, documentation, and international delivery terms before purchase.
