BIOBASE Vacuum Drying Oven(BOV-V/VL)

Name: BIOBASE Vacuum Drying Oven(BOV-V/VL) - Scientific China
SKU: BIOBASE-9FC7E62D0E

Available in stock

Features

BIOBASE Vacuum Drying Oven(BOV-V/VL) is a BIOBASE product for professional laboratory, medical, research, or industrial use. Contact Scientific China for configuration, certification, MOQ, availability, and quotation.

Compare

SKU: BIOBASE-9FC7E62D0E Category: Incubator & Oven Tags: BIOBASE, Incubator & Oven, laboratory equipment, Medical Equipment Brand: BIOBASE

Scientific China

Store

Scientific China

Store

People Also Viewed

Shipping

Additional information

Product Category	Laboratory Equipment > Incubator & Oven

Questions & Answers

Product Enquiry

Description

BIOBASE Vacuum Drying Oven(BOV-V/VL)

Product overview

Vacuum drying oven is a kind of laboratory equipment for drying and heating treatment under vacuum environment, specially designed for drying heat-sensitive, easy to decompose and easy to oxidize substances, when working, it can keep a certain degree of vacuum in the working chamber, especially some items with complex composition can also be dried quickly.

Key features

Product Description
Brochures

Applications

Research, medical, and industrial laboratories
Controlled incubation and culture workflows in life-science and clinical laboratories
Temperature-controlled storage of laboratory, medical, pharmaceutical, or biological materials

Technical specifications

Product Description
Brochures

Features:

1. Outer material : cold rolled steel plate with spraying surface; inner material : SUS stainless steel plate.

2. PID microprocessor temperature control with LED display.

3. Integral molded silicone rubber door seal ring for good air tightness.

4. Toughened bulletproof double glazed doors.

5. With parameter memory function, automatically resume operation when power restoration.

6. The heater is located in the chamber on the shelf, and separate temperature control, with a short heating time, the same level of temperature uniformity is good.(Except BOV-30L/50L)

Model	BOV-30V	BOV-50V	BOV-90V	BOV-215V	BOV-90VL	BOV-215VL
Capacity	23L	53L	91L	213L	91L	213L
Temp. Range	RT+10~200℃	RT+10~250℃	RT+10~200℃
Temp. Fluctuation	±1℃
Vacuum Degree	＜133Pa
Vacuum Display	Pointer-type vacuum pressure gauge	Pointer-type differential pressure vacuum gauge with rotatable vacuum value	LED digital display, push button input of the vacuum value
Vacuum Control	Manual control	Automatic differential pressure control	Pressure sensor+deviation control
Timing Range	0~9999min
Power Supply	AC 220V, 50/60Hz (Standard); 110V, 50/60Hz (Optional) (External transformer)
Consumption	500W	1400W	1600W	2200W	1600W	2200W
Shelf	Aluminum shelf*1	Aluminum shelf*2	Fixed electric heating aluminum plate*2	Fixed electric heating aluminum plate*3	Fixed electric heating aluminum plate*2	Fixed electric heating aluminum plate*3
Standard Accessories	Shelves	Shelves, vacuum pump, vacuum tube
Optional Accessories	Vacuum pump: 2XZ-2(AC 220V, 50Hz; 220V, 60Hz; 110V, 60Hz), vacuum tube, external temperature protection device, LCD temperature controller+RS485, LCD temperature controller+mini dot matrix printer, RS485 to USB converter	External temperature protection device2, LCD temperature controller2, LCD temperature controller2+RS485, LCD temperature controller2+mini dot matrix printer, RS485 to USB converter(BOV-90 series); External temperature protection device3, LCD temperature controller3, LCD temperature controller3+RS485, LCD temperature controller3+mini dot matrix printer, RS485 to USB converter(BOV-215 series)
Internal Size(WDH)	296300270mm	416370346mm	450450450mm	556600640mm	450450450mm	556600640mm
External Size(WDH)	590492468mm	710562544mm	6116411398mm	7217941638mm	6116411398mm	7217941638mm
Package Size(WDH)	670610600mm	790660670mm	7107101550mm	9408101800mm	7107101550mm	9408101800mm
2XZ-2: 580215367mm
Net Weight	55kg	67kg	145kg	208kg	143kg	207kg
Gross Weight	65kg	79kg	171kg	245kg	168kg	244kg
2XZ-2: 23kg

Download: 75-76 Vacuum Drying Oven.jpg

Ordering and configuration

Contact Scientific China to confirm the exact BIOBASE model, required capacity and performance, included and optional accessories, power supply, applicable certifications, installation conditions, minimum order quantity, current quotation, lead time, warranty, training, and international delivery terms.
