BIOBASE -86℃ Freezer 60L 128L

Product overview

The -86 ℃ freezer ‌ is a kind of ultra-low temperature refrigeration equipment, which is widely used in scientific research, medical treatment, biological engineering and other fields. Its main function is to provide an extremely low temperature environment to preserve temperature-sensitive samples and materials.

Key features

Product Description
Brochures

Applications

Professional laboratory, medical, research, or industrial workflows requiring this equipment class
Temperature-controlled storage of laboratory, medical, pharmaceutical, or biological materials

Technical specifications

Product Description
Brochures

Technical Parameters:

Model	BDF-86H60	BDF-86H128
Capacity	60L	128L
Temp. Range	-40~-86℃
Temp. Accuracy	0.1℃
Temp. Uniformity	≤5℃
Temp. Stability	≤6℃
Recovery Time(Recover to -75℃ in an ambient temp. of 25℃)	≤10min
Cooling Time(Cool down to -80℃ in an ambient temp. of 25℃)	≤4h
Control System	Microprocessor control
Display	LED display
Alarm	High/low temperature alarm, power failure alarm(72h), controller failure alarm	High/low temperature alarm, power failure alarm(72h), controller failure alarm, door ajar alarm
Refrigeration Type	Direct-cooling
Refrigerant	R600a/R1150/R14, 145g	R600a/R1150/R14, 170g
Compressor	International famous brand compressor/1
Condenser&Evaporator	Copper tube finned type; built-in coil type copper tube evaporator
Defrost	Manual defrost
Construction	High density polyurethane foam, CFC free
Material	Internal Material	304 stainless steel
External Material	Sprayed steel plate
Door	Outer door: cyclopentane monomer foam door*1 Inner door: /
Noise	53dB(A)
Consumption	550W	528W
Power Supply	AC220V, 50Hz(Standard); 110/220V, 60Hz(Optional)
Casters	Yes
Shelf	/
Standard Accessory	Test port
Optional Accessory	USB interface, RS485 interface, liquid nitrogen backup system, temperature recorder
Internal Size(WDH)	430400350mm	540400580mm
External Size(WDH)	695740985mm	1140730930mm
Package Size(WDH)	8108301180mm	12207801070mm
Net Weight	82kg	98kg
Gross Weight	103kg	135kg

Download: 56-57 -86℃ Freezer & -150℃ Freezer.jpg

Product video

An official product video is attached through the WooCommerce product-video metadata.

Ordering and configuration

Contact Scientific China to confirm the exact BIOBASE model, required capacity and performance, included and optional accessories, power supply, applicable certifications, installation conditions, minimum order quantity, current quotation, lead time, warranty, training, and international delivery terms.
