Features

The -86 ℃ freezer ‌ is a kind of ultra-low temperature refrigeration equipment, which is widely used in scientific research, medical treatment, biological engineering and other fields.

Estimated equipment price only. Shipping, import duties, installation, and logistics are additional and vary by destination and shipping method. We will contact you to confirm the total cost before processing your order.

SKU: BIOBASE-6E10A812CB Category: ﹣86℃ Freezer Tags: ﹣86℃ Freezer, BIOBASE, Lab & Medical Cryogenic Refrigeration Equipment, laboratory equipment, Medical Equipment Brand: BIOBASE

Scientific China

Store

Scientific China

Store

People Also Viewed

Shipping

Shipping Countries: United States (US)

Additional information

Product Category	Lab & Medical Cryogenic Refrigeration Equipment > ﹣86℃ Freezer

Questions & Answers

Product Enquiry

Description

The -86 ℃ freezer ‌ is a kind of ultra-low temperature refrigeration equipment, which is widely used in scientific research, medical treatment, biological engineering and other fields. Its main function is to provide an extremely low temperature environment to preserve temperature-sensitive samples and materials.

Technical specifications

Technical Parameters:

Model	BDF-86V168	BDF-86V348
Capacity	168L	348L
Temp. Range	-40~-86℃
Temp. Accuracy	0.1℃
Temp. Uniformity	±4℃
Temp. Stability	≤6℃
Recovery Time(Recover to -75℃ in an ambient temp. of 25℃)	≤15min
Cooling Time(Cool down to -80℃ in an ambient temp. of 25℃)	≤4h
Control System	Microprocessor control
Display	LED
Alarm	High/low temperature alarm, power failure alarm(72h), controller failure alarm, door ajar alarm
Refrigeration Type	Direct-cooling
Refrigerant	R600a/R1150/R14, 137g	R600a/R1150/R14, 193g
Compressor	International famous brand compressor/1
Condenser&Evaporator	Micro channel condenser; built-in coil type, copper pipe	Built-in coil type copper pipe; copper tube and aluminum fin
Defrost	Manual defrost
Construction	Polyurethane cyclopentane foam
Material	Internal Material	SUS304 stainless steel
External Material	Sprayed steel plate
Door	Outer door: cyclopentane monomer foam door1 Inner door: cyclopentane monolithic foaming, stainless steel door3	Outer door: cyclopentane monomer foam door1 Inner door: cyclopentane monolithic foaming, stainless steel door2
Noise	55dB(A)
Consumption	650W Apparent power: 858VA
Power Supply	AC220V, 50Hz (Standard); 220V, 60Hz, 110V, 60Hz (Optional)
Casters	Yes
Shelf	2	3
Standard Accessory	Test port*2
Optional Accessory	RS485 interface, USB interface, liquid nitrogen backup system, temperature recorder
Internal Size(WDH)	465455820mm	4906121150mm
External Size(WDH)	8448071594mm	8699891924mm
Package Size(WDH)	10009701790mm	102011802130mm
Net Weight	168kg	232kg
Gross Weight	221kg	300kg
